High pressure Jet Cleaner
TW Series
|
High pressure Jet Cleaner
AR Series
|
High pressure Jet Cleaner
K Series
|
High pressure Jet Cleaner
P Series |
PressureJet is leading Manufacturer of India providing High Pressure jet cleaner, High Pressure Water Jet Cleaning Machine, Water Jet Cleaning Machine, High Pressure Jet Pump in India, Malaysia, Indonesia, Gulf countries, Philippines, Russia, Bangladesh, Brazil, South Africa and all over the world.
High pressure water jet cleaning machine is a high pressure reciprocating plunger pump that uses high pressure water jet cleaning machine to remove mold, grime, dust, mud and dirt from surfaces and objects such as buildings, vehicles and concrete road surfaces. A pressure jet washer is also known as power pressure jet washer.
High pressure jet machine direct a pressure jet washer cleaner pump or jet of water against a surface to clean, descale, degrease or prepare a surface. Pressure jet washer cleaners may use either cold water or hot water and steam to perform their function, and the water is often mixed with various cleansers, detergents or solvents. They are used for surface cleaning, or for the demolition of products made of metal, wood, concrete, stone, plastic, glass or other building materials.
High pressure jet washers are available as complete machines or systems, or they can be purchased in component form and built from the ground up, or to replace worn out parts. water blast wheel, and water storage tank.
| |
FLOW
|
:
|
Minimum Flow 10 lpm @ Maximum Pressure 35 bar
|
| |
|
Maximum Flow 28 lpm @ Minimum Pressure 14 bar
|
PRESSURE
|
:
|
Maximum Flow 28 lpm @ Maximum Pressure 35 bar
|
M.O.C.
|
:
|
Brass
|
| |
FLOW
|
:
|
Minimum Flow 8 lpm @ Maximum Pressure 100 bar
|
| |
|
Maximum Flow 40 lpm @ Minimum Pressure 140 bar
|
PRESSURE
|
:
|
Maximum Flow 22 lpm @ Maximum Pressure 500 bar
|
M.O.C.
|
:
|
Brass
|
| |
FLOW
|
:
|
Minimum Flow 40 lpm @ Maximum Pressure 68 bar
|
| |
|
Maximum Flow 655 lpm @ Minimum Pressure 790 bar
|
PRESSURE
|
:
|
Maximum Flow 655 lpm @ Maximum Pressure 905 bar
|
M.O.C.
|
:
|
Brass
|
| |
FLOW
|
:
|
Minimum Flow 5 lpm @ Maximum Pressure 1200 bar
|
| |
|
Maximum Flow 139 lpm @ Minimum Pressure 50 bar
|
PRESSURE
|
:
|
Maximum Flow 139 lpm
@ Maximum Pressure 100 bar
|
M.O.C.
|
:
|
Brass
|
Some High Pressure Jet Cleaner, in combination with a particular nozzle, allow detergent to be introduced into the water stream, assisting in the cleaning process. Two types of chemical injectors are available: a low-pressure injector and a high pressure injector.
The pumping unit is the pressure generator used to force out the carrier fluid at high velocity. Plunger-type High Pressure Jet Washers are commonly used to generate high pressure water jet cleaning pump for water jet cleaning machine and wet or water abrasive blasting for non-abrasive pressure jet washing machine or rinsing. Crankshaft driven plunger pumps are commonly used for pressure generation. Crankshaft driven plunger pumps may be more efficient in electrical energy costs compared to intensifiers. Crankshaft driven plunger pumps also provide a virtually ripple free pressure source in comparison to intensifiers. Dust collection or filtration systems remove fine particle sizes of abrasive, swarf, grease or other blasting waste (removed scale or stock in the form of dust or fine swarf) that would otherwise contaminate the environment.
Water tanks or hoppers are used by water pressure jet washers for the storage of dry abrasive grains, blasting media or abrasive-water slurry mixtures.
THE MOST BASIC HIGH PRESSURE JET CLEANER CONSISTS OF:
-
A motor/engine
-
High Pressure Hose
-
Trigger Operated Gun
-
Unloader Valve
-
Lances
-
Nozzles
-
Pressure Relief Valve
-
Pressure Gauge
