Hydro Test Pump Equipment
Hydro Static Pressure Test Pump, Hydrotest Pump, Pressure Test Pump manufacturer - PressureJet
Hydro Test Pump- Catalogue

Click to make an enquiry







"Hydro Test Pump" is a diagnostic technique to perform High Pressure Hydro Test of tubes,pipes,hoses,cylinder,Hydro testing of pressure vessels & boilers,High Pressure Hydro Testing of cross country pipe lines,valves,castings,components etc. for leaks or defects. The Hydro test pump equipment is used to check the component to be tested is being filled up with an incompressible liquid, usually water or oil. With the help of a positive displacement reciprocating plunger pump incorporating appropriate safety relief and controls, the pressure of the test component is slowly increased to a predetermined set point and held for a predetermined time. Visual inspection is subsequently performed to determine whether any leakage exists or the pressure reduces from set pressure point.



PressureJet offers wide range of high pressure hydro test pumps & equipment ranging from 1 lpm to 770 lpm and pressure up to 1400 bar. Hydro Test Pump & Systems is either electric motor driven or engine driven.



Our High Pressure Hydro Test Machine are used of various applications i.e. valve, pipe & tube, tanks, rubber hose, cross country pipe line and many more...



We have variety of pressure test pump, suitable to particular application.





Motorized Hydro Test Pump








 Motorized Hydro Test Pump

Electric motor driven High Pressure Hydro Test Pump Equipment is basically Reciprocating Plunger Pump, having Flow rate range is from 1 LPM to 770 LPM and Pressure range is from 20 bar (290 PSI) to 1200 bar (17405 PSI). This product is recommended for frequent usage of the equipment and power is available...












High pressure hydro testing pump

 Diesel Engine Driven High Pressure Hydro Test Pump

Diesel Engine driven High Pressure Hydro Test Pump is High Pressure Plunger Pump having Flow rate range is from 20 bar (290 PSI) to 1200 bar (17405 PSI). This product is recommended for frequent usage of the Hydrotest Pump and power is not available.







pneumatic hydro pressure test pump

 Pneumatic Operated Hydro Test Pump Equipment

AIR OPERATED Hydrostatic Pressure Test Pump is having maximum pressure range up to 2500 bar (36259 PSI). This product is recommended where frequent Hydro Testing is not required, as working cost is higher than electric driven pump. However, the initial cost of the product is economic with compare to electric driven hydro test pump.















Hand operated hydro test pump

 Hand Operated Hydrotest Pump

Our Hand Operated Hydro Test Pumps are widely used in domestic and international market. This is available at affordable price. Ideal for testing residential water lines. Also for pressure testing small, pressure tanks, sprinkler, boiler and solar systems. Lightweight and easy to use. Equipped with shut-off valve, gauge, and pressure relief valve. Hand Operated Hydrostatic Test Pumps is light weight, economical andeasy to use to test residential plumbing lines, small pressure tank, mini boilers, sprinklers etc...
